INT8 Quantization: What the Numbers Actually Mean

1. Quick-look, “in a nutshell”

You run a model in INT8 and it is 30% faster than FP32. You run the same model in INT8 with a different framework — same hardware, same batch size — and it is 2% faster. You run it again with a different calibration dataset and the accuracy drops by 4 points. Quantization is not one thing.

INT8 quantization is the process of representing model weights and/or activations using 8-bit integers instead of 32- or 16-bit floating-point values. Done correctly, it delivers:

• 4× memory reduction vs. FP32 (32 bits → 8 bits per value)
• 2–4× inference throughput on hardware with INT8 tensor cores (NVIDIA T4, A10G, most mobile NPUs)
• Accuracy within 0.5–1% of FP32 on most standard benchmarks, for models above ~100M parameters

Done incorrectly — wrong calibration, wrong granularity, wrong framework path — you get most of the accuracy loss with little of the speed gain.

2. The two things quantization does

Quantization maps floating-point values to integers using a scale and a zero-point:

x_int = round(x_float / scale) + zero_point
x_float ≈ (x_int - zero_point) × scale

The scale and zero-point are the parameters you are computing when you “calibrate” a model. Everything else — symmetric vs. asymmetric, per-tensor vs. per-channel, PTQ vs. QAT — is a choice about how and where those parameters are calculated.

3. Symmetric vs. asymmetric quantization

Symmetric

The quantization range is centred at zero. Zero-point is always 0:

x_int = round(x_float / scale)
scale = max(|x|) / 127

Values map to the range [-127, 127]. The zero-point is implicit, so dequantization is a single multiply — fast on hardware.

Symmetric works well for weights, which are typically zero-centred after training with weight decay.

Asymmetric

The range is shifted to fit the actual distribution:

x_int = round(x_float / scale) + zero_point
scale = (max(x) - min(x)) / 255
zero_point = round(-min(x) / scale)

Values map to [0, 255]. Dequantization requires both a multiply and a subtract, but the range adapts to the actual data — crucial for activations like ReLU outputs, which are always non-negative and have a mean far from zero.

4. Per-tensor vs. per-channel quantization

This is where most accuracy-vs-speed trade-offs live.

Per-tensor quantization uses a single scale and zero-point for an entire weight matrix or activation tensor. Fast to compute, fast at runtime — but if some channels have much larger values than others (common in deeper layers), the scale is dominated by the outliers and small-magnitude channels lose precision.

Per-channel quantization computes a separate scale per output channel (for weights) or per token/feature (for activations). Each channel gets its own range, so outlier channels do not distort the rest.

Per-tensor:
┌──────────────────────────────────────┐
│  scale = 0.042 (for entire matrix)   │
│  [W₀₀  W₀₁  W₀₂  ...  W₀ₙ]         │
│  [W₁₀  W₁₁  W₁₂  ...  W₁ₙ]         │
└──────────────────────────────────────┘

Per-channel:
┌─────────────────────────────────────────────────┐
│  scale₀ = 0.003 → [W₀₀  W₀₁  W₀₂  ...  W₀ₙ]  │
│  scale₁ = 0.091 → [W₁₀  W₁₁  W₁₂  ...  W₁ₙ]  │
│  scale₂ = 0.017 → [W₂₀  W₂₁  W₂₂  ...  W₂ₙ]  │
└─────────────────────────────────────────────────┘

Per-channel quantization is standard for weights in production systems. The accuracy gain over per-tensor is typically 0.5–3% on classification tasks, and can be much larger on models with high channel-to-channel variance (transformers, ResNets with skip connections).

For activations, per-channel (or per-token in transformer terminology) is harder — you don’t know the channel values at quantization time, so you need to calibrate dynamically or use statistics from a representative dataset.

5. Post-Training Quantization (PTQ) vs. Quantization-Aware Training (QAT)

PTQ: quantize after training

You take a trained FP32 model and quantize it directly, using a small calibration dataset (typically 100–1000 samples) to measure the activation distributions.

FP32 model → calibration run → compute scales → INT8 model

PTQ is the default approach for most deployments. It requires no retraining and works well on models with >100M parameters. The main risk is outlier activations — a small number of channels with very large values — which inflate the scale and waste precision for all other channels. LLMs are particularly prone to this (see SmoothQuant and GPTQ for solutions).

QAT: quantize during training

You simulate quantization during the forward pass using “fake quantize” nodes, then train (or fine-tune) the model so its weights adapt to quantization error.

FP32 model → insert fake-quantize ops → fine-tune → remove fake-quantize → INT8 model

QAT recovers 1–3% accuracy over PTQ on small models, and can push accuracy essentially to FP32 parity on models below ~50M parameters. The cost is retraining time — typically 10–20% of the original training compute.

6. The calibration dataset matters more than you think

For PTQ, the calibration dataset determines the activation statistics — and therefore the scales. A calibration set that does not represent your production input distribution will produce scales that clip real inputs or waste range on values you never see.

Rules of thumb:

• Use 128–512 samples from your actual production traffic, not the validation set
• For NLP models, include samples of varied lengths — short sequences have different activation statistics than long ones
• For vision models, include samples across your brightness/contrast range
• Run calibration with batch_size=1 if your model’s activations vary significantly with batch size

The difference between a well-chosen and a poorly-chosen calibration set can be 1–3% accuracy on a difficult task.

7. Software paths that actually use INT8

Not all “INT8 inference” paths use INT8 arithmetic end-to-end. Some frameworks quantize weights but dequantize to FP32 before matrix multiplies — giving you the memory bandwidth savings but not the compute savings.

On NVIDIA hardware, TensorRT is the reference path for true INT8 throughput. On CPU, ONNX Runtime with the CPU execution provider uses AVX-512 VNNI (on Intel) or NEON (on ARM) for genuine INT8 matrix multiply.

8. A worked example: quantizing a ResNet-50

import torch
from torchvision.models import resnet50
from torch.ao.quantization import get_default_qconfig, prepare, convert

model = resnet50(pretrained=True).eval()

# Step 1: Set quantization config (symmetric weights, asymmetric activations)
model.qconfig = get_default_qconfig('x86')  # or 'arm' for mobile

# Step 2: Insert observer nodes
model_prepared = prepare(model)

# Step 3: Calibration run (use your representative data)
with torch.no_grad():
    for images, _ in calibration_loader:
        model_prepared(images)

# Step 4: Convert to INT8
model_int8 = convert(model_prepared)

# model_int8 is now a fully INT8 model
torch.save(model_int8.state_dict(), 'resnet50_int8.pt')

The qconfig encodes the symmetric/asymmetric choice and the per-channel vs. per-tensor decision. 'x86' selects per-channel symmetric for weights and per-tensor asymmetric for activations — the configuration that maximises accuracy on x86 hardware with VNNI support.

9. Quick-look summary

INT8 quantization is not a checkbox — it is a pipeline with four or five decisions, each of which affects both accuracy and throughput. The good news is that for most models above a few hundred million parameters, the default choices (per-channel weights, asymmetric activations, PTQ with a small calibration set) get you within 1% of FP32 accuracy and 2–4× the throughput. The bad news is that the defaults are different in every framework, and none of them tell you this clearly.
